Thông số kỹ thuật
Compatibility
Single Intel Xeon E3-1200 V5 processors
TDP
80 W
Socket
H4 LGA 1151
Chipset
Intel C232
Memory
4 x DIMM slots, 64 GB (max)
Dual-channel DDR4 ECC UDIMM memory at 2133 MHz
68.256 GB/s memory bandwidth (max)
40-bit physical address extensions
LAN
2 x 1 GbE LAN port (Intel I210)
RAID
Software…
Thông số kỹ thuật
| Compatibility | Single Intel Xeon E3-1200 V5 processors |
| TDP | 80 W |
| Socket | H4 LGA 1151 |
| Chipset | Intel C232 |
| Memory | 4 x DIMM slots, 64 GB (max) Dual-channel DDR4 ECC UDIMM memory at 2133 MHz 68.256 GB/s memory bandwidth (max) 40-bit physical address extensions |
| LAN | 2 x 1 GbE LAN port (Intel I210) |
| RAID | Software RAID RST (0,1,10,5) and ESRT2 (0,1,10) |
| External I/O Ports | USB: 2 x USB 2.0 (back panel) 2 x USB 3.0 (back panel) Ethernet: Dual 1GBase-T (RJ45) Video: VGA graphics via BMC (15-Pin Sub-D VGA) |
| Internal I/O Connectors | 1 x USB Type A 2.0 connector 2 x USB 2.0 port via header for front-panel 1 x DH-10 serial port connector 1 x 2×12-pin SSI front-panel header 6 x SATA III via 7-pin SATA connector 1 x SATA IV Apacer SATA DOM connector |
| Expansion Slots | 1 x PCIe 3.0 x8 slot with x16 connector 1 x PCIe 3.0 x4 slot with x8 connector 1 x PCIe 3.0 x8 slot with x8 connector |
| Integrated BMC with IPMI | IPMI 2.0 |
| OS Supported | Windows Server 2012 R2 with Hyper-V, x64, and EFI Windows 7 Red Hat Enterprise Linux Server 7.0 with KVM (x64 and UEFI) Red Hat Enterprise Linux Server 6 Update 5 with KVM (x64 and UEFI) SUSE Linux Enterprise Server 12 with Xen (x64) SUSE Linux Enterprise Server 11 SP4 with Xen (x64) Ubuntu 14.04 |
| Advanced Technologies | Virtualization Technology for Directed I/O (VT-d) Node Manager Rapid Storage Technology enterprise I/O Acceleration Technology |
| Intel Platform Protection Technology | Trusted Execution Technology |
| Dimensions | 9.6 x 9.6″ (24.4 x 24.4 cm) |
