Mô tả chi tiết |
|
Hãng sản xuất |
GIGABYTE |
Chủng loại |
H97-D3H |
CPU hỗ trợ |
Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel®Pentium® processors/ Intel®Celeron® processors in the LGA1150 packageL3 cache varies with CPU (Please refer "CPU Support List" for more information.) |
Chipset |
Intel® H97 Express Chipset |
Bộ nhớ trong |
DDR3 1600/1333 MHz, 4 x 1.5V supporting up to 32GB |
VGA onboard |
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60Hz 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@24Hz or 2560x1600@60Hz Maximum shared memory of 1 GB
|
Card mạng |
Intel® GbE LAN chip (10/100/1000 Mbit) |
Âm thanh |
Realtek® ALC1150 codec / High Definition Audio / 2/4/5.1/7.1-channel / Support for S/PDIF Out |
Khe mở rộng |
1 x PCI Express x16 slot, running at x16 (PCIEX16) 2 x PCI Express x1 slots 3 x PCI slots |
Chuẩn lưu trữ |
1 x M.2 PCIe connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe SSD support) 1 x SATA Express connector 6 x SATA 6Gb/s connectors (M.2, SATA Express, and SATA3 4/5 connectors can only be used one at a time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is installed.) Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
Cổng giao tiếp trước và sau |
1 x PS/2 keyboard/mouse port / 1 x D-Sub port /1 x DVI-D port / 1 x HDMI port / 4 x USB 3.0/2.0 ports / 2 x USB 2.0/1.1 ports / 1 x RJ-45 port /6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In) |
Công nghệ tích hợp |
Dual-BIOS , APP Center , @BIOS ,EasyTune , EZ Setup , Fast Boot ,Game Controller ,ON/OFF Charge ,Smart TimeLock , Smart Recovery 2 ,System Information Viewer ,USB Blocker , Q-Flash , Smart Switch ,Xpress Install , Cloude Station , Lan Optimizer , Intel SBA. |
Kích thước |
ATX Form Factor; 30.5cm x 21.4cm |
Phụ kiện đi kèm |
(Hộp / Sách hướng dẫn sử dụng / Đĩa Driver / Cable tín hiệu Sata / Chặn main ….) |
